Arbitrary Resources Introduces ArbIQ, a Powerful and Flexible Modulated Signal Generation Tool for Arbitrary Waveform Generators (AWG) ArbIQ Software along with any Arbitrary Waveform Generator allows the design and manufacturing engineer to create advanced multi-carrier wireless signals easily in a wide variety of applications and test conditions. It can generate baseband and IF/RF signals in both analog and digital formats so modern SDR (Software Defined Radio) designs can be tested with one single signal source. Barcelona, Spain, October 17th, 2011 – Arbitrary Resources, S.L., a R&D and Consulting company for the T&M Industry, announced ArbIQ, a Wireless Signal Creation software application for a wide range of Arbitrary Waveform Generators (AWGs) from multiple vendors. ArbIQ greatly simplifies the work of design and manufacturing engineers when it come to obtain real-world stimulus to apply to the latest generation of wireless devices implementing SDR (Software Defined radio) architectures. ArbIQ allows creating digitally modulated signals in a wide variety of situations as it supports the generation of high-quality baseband (IQ) and IF/RF signals in analog o digital format, even simultaneously when applied to a multi-channel arb. It can create ideal or distorted dissimilar multi-carrier signals where users can define all the modulation parameters and distortions independently for each carrier. The ArbIQ package supports multiple general-purpose modulation formats such as QPSK, QAM, or FSK, and, at the same time, it fully supports channel-coded signals for applications such as mobile telephony (UMTS, CDMAOne), wireless networks (802.11b, Zigbee, Bluetooth), or digital television (8/16VSB, DVB-C). It even includes WiMedia and DVB-T sample signals, among others, for basic test and educational purposes. ArbIQ’s flexibility and openness make possible targeting virtually any AWG in the market, raging from value instruments up to state-of-the-art AWGs with sampling rates beyond 10GS/s, no matter their vertical resolution, analog bandwidth, or waveform memory size. Standard features in ArbIQ include support for a variety of modulation schemes: OOK, BPSK, QPSK, Offset-QPSK, DQPSK, p/4-DQPSK, 8PSK, O-8PSK (EDGE). QAM16/32/64/128/256/512/1024. 8/16VSB. 2/4/8/16/32FSK, GMSK. ASK, bandwidt-limited Gaussian noise with crest factor control. Symbol synchronous clocks, sinusoidal analog AM, PM, and FM. CDMA (as per CDMAOne) and UMTS/3GPP downlink signals including full channelization and synchronization information. 3GPP HSDPA and Compressed modes are also supported. A wide range of baseband filters allows generating accurate waveforms according to most wireless standards. Product options add the capability to create RADAR and generic OFDM signals. ArbIQ is not a closed environment as users can import their own data, baseband filters, and even IQ signals. It even incorporates a comprehensive constellation edition tool so users can design their own modulation schemes right away. Examples such as DVB-S2’ 16 and 32APSK constellations are provided. An option allows exporting the data in a variety of binary and ASCII-delimited formats so further processing and documentation through external tools is possible. "ArbIQ adds to any AWG the capability of generating complex and accurate digitally modulated multi-carrier signals. Its flexibility allows any user to create any signal to be applied to any point in the signal chain of any transmitter or receiver" said Joan Mercadé, General Manager, Arbitrary Resources, "and it does so while fully exploiting the target AWGs performance in terms of sampling rate, vertical resolution, number of channels and record length. Ease-of-use and usability is a very important aspect so users are isolated from the complex aspects of both the signals and the instruments while offering a very fast signal compilation time.” ArbIQ incorporates advanced algorithms to avoid, not only make-up, wrap-around artifacts when signals are generated in continuous mode, and it does for all the carriers no matter the carrier frequency, symbol rate, or modulation scheme. Impairment Support Margin and DSP algorithm test requires impaired signals. ArbIQ can add a variety of impairments including the following: Linear distortions: Carrier feed-through, quadrature error and imbalance. Non-linear distortions: AM/AM, AM/FM, amplifier clipping. Multi-path. Power ramping. I/Q delay. Impairments may be applied to each carrier independently. Analysis and Validation Tools ArbIQ incorporated a wide range of analysis and visualizations tools in order to properly validate and document any synthesized signal. Available tools make ArbIQ useful by itself for educational purposes as it can show the most important characteristics of any modulation and the effects of changing signal parameters in the modulation, time, and frequency domains. Analysis tools include: Constellation and Phase diagrams Eye diagrams. Spectrum. CCDF (Complementary Cumulative Distribution Function) with crest factor analysis. I/Q versus time. Histogram, gray scale signal analysis in the IQ plane. Application Specific Support The standard ArbIQ package supports most test situation related with general-purpose wireless and mobile telephony. Additional options support specific applications: RADAR: Spread-spectrum, chirp generation, Barker-codes support. Generic OFDM: It allows for the generation of user defined OFDM schemes. It also adds pre-defined set-ups for DVB-T, IEEE802.11, WiMedia, WIMAX, and others. Coherent Optical Communications: It adds specific signal parameters such as baseband filtering and coding (RZ, NRZ), impairments such as CD and PMD, and analysis tools such as power eye diagrams. For more information on these and additional features and capabilities, please contact Arbitrary Resources at http://www.arbitraryresources.com. Pricing and Availability Version 1.0 of ArbIQ is ready for delivery. ArbIQ is available starting at € 900. Prices are E.U. MSRP. About Arbitrary Resources, S.L. Arbitrary Resources, S.L. is a R&D and consulting services provider for the Test & Measurement Industry. It specializes in extending the measurement capabilities of existing equipment to successfully serve new areas of application, such as wireless and broadcast testing. With more than 20 years of experience in the measurement business and the development of complete solutions, Arbitrary Resources develops OEM software packages, participates in big projects for major T&M manufacturers, and adapts world-class technology from leading research groups in universities for commercial use. Headquartered in Barcelona, Spain, Arbitrary Resources works with customers located in Europe, USA, and Asia. Arbitrary Resources' Web address is www.arbitraryresources.com. Download press release in Pdf format Download press release in Word™ format Download ArbIQ Data Sheet in Pdf format Download press release images
